Products
High Efficiency
Transmission: slewing bearing. 35-40 loads each hour. Noiseless, long service life, maintenance-free, no need to add additional counterweight.
More Powerful
Mechanical filming way
100% film-clamping effect
Cylinder film-cutting
Save Cost
Maximum up to 400% pre-stretch rate
Minimum the value of each meter of stretch film
Standard constant releasing film
Fixed-pointed wrapping quantitative use film
Better spare parts
SICK proximity switch, photoelectric sensor
Weidmuller terminal board
SIEMENS PLC
SIEMENS Inverters
| Model | Smart Wasp T1000 | Spare Parts | Brand |
| Maximum wrapping speed | 35-40 loads/hour | Inverter | SIEMENS |
| Max pallet size | 1.2x1.2m | Position sensor | SICK |
| Maximum Wrapping Height | 2000mm | PLC | SIEMENS |
| Ring Speed | 0-30RPM(Adjustable) | Travel Switch | OMRON |
| Ring Size | 2000mm | Ring drive Motor | JSK |
| Ring Drive Power | 1.5PH | Relay | OMRON |
| Film &Clamp Cut | Automatic (Heat type) | Touch screen | SIEMENS |
| Standard Film Width | 500mm | Switch | Schneider |
| Constant Film Delivery Force | Standard | Cylinder | AIRTAC |
| Standard Pre-Stretch | 250% | Up and down motor | JSK |
| Film Capacity | Diameter: 250mm | ||
| Top pressure function | Optional | ||
| Lifting up conveyor | Optional | Special Process | Introduction |
| Top sheet dispenser | Optional | Frame | Steel |
| Paper corner fixer | Optional | Printing | Metallic Paint |
| Machine Size | 3825*2900*3940mm | Cutting | Laser |
| Machine weight | 2000KG | ||
| Voltage | 380V/60HZ |
