| Robot Wrapping Machine Technical Parameters | |||||||||||
| Brand | Smart Wasp | Model | R600 | ||||||||
| Length | 1586mm | Battery type | Lead-acid cell | ||||||||
| Width | 871mm | Battery capacity | 48V (4*12V 100Ah) | ||||||||
| Operating width | 1390mm | Battery brand | TIANNENG BATTERY | ||||||||
| Height | Standard 2420mm (Optional) | Battery model | 6-EVF-73H | ||||||||
| Pre-stretch rate | 350% | Transverse volocity | 67m/min | ||||||||
| Max Wrapping Height | 2800mm | Running Speed | 1-16cpm | ||||||||
| Control Lever Height | 1076mm | Up&down speed | 5m/min(Adjustable) | ||||||||
| Pallet Size | >=800*800mm | Film Width | 500mm | ||||||||
| Standard Wrapping Height | 2000mm | Film Diameter | 250mm | ||||||||
| Machine Weight | 330kg | Core diameter | 76mm | ||||||||
| Max Wrapping Weight | No Limited | Working time | 8 Hours | ||||||||
| Power | 1.2KW | Driven Type: | Electric | ||||||||
| Voltage | 220V 50Hz | Operation temp | 0-40℃ | ||||||||
| PLC | X-LINE | ||||||||||
| Certification | CE | ||||||||||
