| Specification: | |||||||||||
| Machine Information | Stretch Hood Machine T1400 | Spare Parts | |||||||||
Working Speed | Output/hr(@H:2000-2800 mm):60-70 load/H Output/hr(@H:1200-2000 mm):90-100 load/H Output/hr(@H:800-1200 mm):100-120 load/H | Motors: | SEW、SIEMENS | ||||||||
| Pneumatic: | FESTO | ||||||||||
| Maximum pallet size | 1450×1450mm | Electrical: | SIEMENS | ||||||||
| maximum pallet height | 2200( 2800mm optional) | Driver: | KANA | ||||||||
| Transport height,minimum(mm) | 620mm | Sealing transformer: | Siemens | ||||||||
| Film Thickness | 120mic | Sensors: | Sick | ||||||||
| Stretch Rate | 42% | Terminals: | Phoenix contact | ||||||||
| Power connectionVolt/Amp) | 3×380V/37A | Fuses: | Schneider Electric | ||||||||
| Power consumption(KW/h) | 20 | Circuit breaker: | Siemens | ||||||||
| Power consumption(W/h,standby) | 180 | Contactors: | Siemens | ||||||||
| Air consumption(m3/h) | 0.5~0.8 | Operation | Fully automatic | ||||||||
| Operating temperature | -10~50℃ | Noise level | Low(product &stretch level dependant) | ||||||||
| Machine dimensions L×WxHmm | 5167x3462x4305mm | PLC | SIEMENS 1500 | ||||||||
| Machine weight(kg) | 3800KG | HM I | SIEMENS | ||||||||
